MagicCare - Model Bora Plus SC69P00 -Piston Nebulizer Compressor

SPEED SELECTOR IN “MIN” POSITION

A slower flow ensure optimal particle size value up to the lower respiratory tract, limiting the dispersion of medication into the environment.

SPEED SELECTOR IN “MAX” POSITION

The air flow into the nebulizer is enhanced and medication is delivered faster, reducing the treatment time, ensure optimal particle size value and limit the dispersion of medication into the environment.

• Delivery ml/min (approx.): 0,50 MAX - 0,28 MIN
• MMAD: 3,86 MAX- 3,69 MIN
• Breathable fraction < 5 μm %: 62,5 MAX - 64,2 MIN
• Maximum fill volume: 8 ml

• Power supply/Power: 230 V ~ 50 Hz/140 VA
• Air filtering: For better quality, the compressed air is extracted external of the housing and filtered using a high efficiency filter system (porosity 50/70 μm)
• Compressor air output: 10 l/min (approx.)
• Max pressure: 2,6 ± 0,4 bar
• Sound level (at 1 m): 57 dB (A) (approx.)
• Dimensions: 18 (length) x 30 (width) x 12 (height) cm.
• Handset Weight: 1,5 Kg
• Warranty: Please refer to your local dealer
• Approvals: TÜV
