FFV - Manual Ball Valve

FromFluid Force Valves (FFV)

SHARE

FFV Manufacture Single Piece,Two Piece & Three Piece Design Ball Valve. Cast Steel Ball Valves Have Been Designed To Meet The Requirements BS 5351/ASME B 16.34 / API 6D /API 608. Face to Face an End to End dimensions conform to ASME B 16.10 / BS 2080 /API 6D/ DIN. End flange dimensions conform to ASME B 16.5 / API 605 / BS 3293 / DIN. Butt weld end dimensions conform to ASME B 16.25. Screwed Ends to BSP / BSPT / NPT Female Threads. Socket Weld Ends to ANSI-B-16.11.

Most popular related searches

Body ASTM A 216 WCB / A 217 WC6 / A 217 WC9 / A 217 C5 / A 217 C12 / A 351 CF8 / A 351 CF8M / A 351 CF3 / A 351 CF3M, / IS 210 GR. FG 200 / 220 / Bar Stock / M.S. / HAST B / HAST C
Ball ASTM A 216 WCB / A 217 WC6 / A 217 WC9 / A 217 C5 / A 217 C12 / A 351 CF8 / A 351 CF8M / A 351 CF3 / A 351 CF3M, / IS 210 GR. FG 200 / 220 / Bar Stock / M.S. / HAST B / HAST C
Size 15 mm to 400 mm
Seal / Seat PTFE / Gft/ Spiral Wound SS 316 with Graphoil
Stem ASTM A 182 F304 / A 182 F316 / A 182 F 6a, AISI304/ AISI316 / AISI304L / AISI316L / ALLOY20
Lever Carbon Steel with PVC, SS - 304/MS. Cd. Plated
Pressure Rating 150#,300#
End Connection Screwed type, Socket welded type, Flanged type, Triclover end (BSP/ NPT)
