Emco Wheaton - Model B0030 -Marine Loading Arm
Our B0030 Marine Loading Arm is preferred when loading / unloading sea-going tanker ships and its capability has been proven with many years of trouble free operation world-wide.
Most popular related searches
The B0030 includes a rigid link pantograph balancing system with independent counterweights directly linked to the inboard and outboard arm. This ensures accurate balance throughout all manoeuvring and connecting positions.
The self-supporting design provides not only high safety standards for easy operation, but also lowest possible jetty loads which minimizes the cost for the jetty itself.
DESIGN
- Fully balanced with independent counterweights for inboard and outboard arm
- Self-supporting system
- Less manpower due to low weight
- Swivel joints either welded-in or flanged
- For transfer of mineral oil, chemicals and Liquified Petroleum Gas (LPG)
- Seals available in Buna-N, Viton, PTFE or other specific materials
- Range alarm system
- Drainage connections
- Emergency release system (ERS)
- Hydraulic operation
- Hydraulic or manualquick coupler
- Insulation flange
- Nitrogen purge line
- Drain line
- Vacuum breaker
- Vapour return line
