Marley HVLS - Model MGF -Gear Fan
Geared HVLS fans have stood the test of time and have provided reliable and effective air management solutions with minimal maintenance required. The efficiency of geared motors results in unparalleled cost savings and the reliability translates to lower maintenance costs and lower downtime.
Known for their exceptionally low maintenance and energy efficiency, they are also very silent and their longevity means that there is no degradation in power throughout the life of the fan. Another significant cost saving benefit is that our fans have a very long service interval which translates to low or negligible downtime.
Aluminium alloy grade for 240mm wide blades with a cambered airfoil. Satin matte finish with 15 micron anodizing and single piece M3 hub for added strength and rigidity. VFD made in Japan by Fuji electric.
Marley HVLS fans are secured with blade toppers above blades and safety ring Z brackets. In addition 3 mm GI wires of SS 304 grade to prevent fan swaying due to imbalance caused by crosswind.
Marley HVLS fans provide massive natural air movement giving you wide coverage cooling with minimum expense. With our fans, you will reduce your carbon footprint and create a comfortable environment at minimum expense.
Control System
- Using Fuji Electric – Inovance AC Drive Advanced Model IP65, CE & UL Certified Drivers
- Protection from over current, Overvoltage & Undervoltage.
- OPtion for reversible operation
