Mars Mineral - Model D - Deep Drum Pelletizer
The Mars Mineral Deep Drum Pelletizer is an inclined, deep-drum unit featuring an integral, rear-mounted auger feeder. Its deep-drum design makes it ideal for applications requiring long retention time for densification and the production of large-diameter pellets. The Deep Drum Pelletizer is an excellent choice for applications that require large, dense pellets for recycling, transportation or disposal.
- Inclined deep-drum design
- Versatile unit for broad range of applications
- Integral rear auger feeder
- Compact and self-contained
The Deep Drum Pelletizer’s low headroom requirement allows for installation in existing structures and the patented, rear-feed auger provides an excellent opportunity to mix dry binders when required.
The drum of this pelletizer provides 30° angle adjustment and incorporates a binder spray system and adjustable wear-resistant scrapers. Other features of the unit include 1800 rpm motors with gear reducers and the specially-designed auger feeder.
Material enters the drum center through the feeder from the rear. This feeder consists of a larger conditioning auger which surrounds the feed auger. The conditioning auger arrangement eliminates material bridging in the feed hopper.
Because the feed enters below already-processed material in the drum, dusting is kept to a minimum. This feature augments the unit’s compact design, making it particularly suited for installation in space-restricted areas.
