Gester - Model CT-C13 -Martlndale Abrasion and Pilling Tester

Application of martindale tester:

• The Martindale Abrasion and Pilling Tester is the standard method of determining the wear resistance of textiles or leather and the resistance to pilling. Samples are rubbed against known abradents at low pressures and in continuously changing directions and the amount of abrasion or pilling is compared against standard parameters. Adaptable to test a wide range of applications including textiles, socks, leather coated upholstery carpets, wood and shirt collars.
• Four models are available, with 4. 6. 8 and 9 Abrading Tables respectively.

Standards of martindale tester:

• Abrasion: GB/T 21196.2, GB/T13775: ISO 12947, ASTM D4966, IWS TM 112, M&S P19, Next 18, SN 198529, TWC 112, JIS L1096 (IS017076-2 ball plate method optional)
• Pilling: GB/T4802.2, IS012945-2, ASTM D4970, IWSTM 196, M&S P17, NextTM26, SN 198525

1. Test Standard: Lissajous figure.
2. Working positions: 4: 6: 8, 9 optional.
3. Counting Method: 1) count up. 2) count down.
4. The unique design allows removal of individual sample holders 5.for examination without lifting the top motion plate.
5. Standard sample holders with 9 and 12kpa weights included.
6. PLC, 7 inches color touch screen, Chinese and English operation interface.
7. Weights and key components are made up by stainless steel, which is well-formed and durable in use.
8. To prevent distortion, the top motion plate was special made up by 316 aluminum alloy.
