GRYF - Model XB1-E -Measuring Head Wireless Probes
Measuring head for determining the conductivity and the concentration (wireless). The conductivity could be determined using this measuring head XB1-E. The sensors are connected to the measuring head using a connector that is hidden inside the head. After connecting the sensor measuring system detects a measured quantity without the user having to adjust anything and the system is ready to measure or calibrate.
Most popular related searches
conductivity monitoring
temperature monitoring
conductivity resistivity
connection head
sensor system
remote monitoring
Attributes: Data
- Probe power supply: baterry
- Protection: IP40, submersion design IP68
- Conductivity measuring range: Conductivity: 0,00 µS/cm – 500,0 mS/cm
- Resistance:: 5,0 Ω – 2000 kΩ
- Concentration: 0 – 200 g/l, 0 – 20%
- Number of measuring ranges: Conductivity, Resistance 5 aut/man, Concentration 5 aut/man
- Konc. NaCl ,KCl, NaOH : 0 – 200 g/l, 0 – 20% in 5 ranges
- Accuracy of conductivity measuring : 0,5 %; ± 1dig
- Temperature compensation: automatic: -10 – 110 °C
- Constant of temperature correction: flow setting 0 – 3% / K, due to the norm EN 27 888
- Reference temperature: 20°C / 25°C
- Temperature measuring range: -20 – 120 °C
- Accuracy of temperature measuring: ± 0,2 °C; ± 1dig.
- Autocalibration: Yes
