Melodis - Model 100 -Mixer Feeder Bucket

A version of the Melodis is available for a “100% chopped grass silage” ration thanks to its spiral mixer made in Hardox (Melodis 100). This model has been especially designed for mixing and feeding chopped grass silage (maximum 6 cm length maximum) for a Total mixed ration (maize, grass, dry food) and optimizes the ration incorporating fiber (short straw).

• Spiral mixer with Hardox blades. Double driving of the spiral mixer by 2 integrated hydraulic motors.
• Blade with chains for Melodis.100
• Bucket bottom in 450-Hardox
• OMEGA shape to optimize the mixing flow in forward and backward motion
• Hydraulic feeding door in Hardox with large opening synchronized with the distribution (Right and Left is optional)
• Left hand side discharge for telescopic handler – Right hand side is on request
• Hardened heels
• Adjustable, removable and bolted adaptation for any type of agricultural machinery handler

• Total versatility of the bucket: mixes and discharges 100% chopped grass silage, maize or a Total Mixed Ration incorporating fiber without disintegration. Quantity of ration can be adjusted depending on the type and age of herd.
• HARDOX structure for a strong and light bucket. Optimized volume.
• Easy to handle and safe (excellent visibility from the cab).
• Economical, cost effective: 1 machinery handler only to cut, mix, feed.
• Fast and precise mixing/feeding.
• No disintegration of the ration.
• Large opening door: important distribution flow.

• Right and left distribution
• Hydraulic grab
• Mobile rotor
• NEW: Stainless steel sheet 2mm
• Extra blade (welded or bolted)
• Inversion direction kit for the mobile rotor with a rotation mark
• EMILY Connect plug
