Mempex - Model OR-1.5 -Collapsible Mobile Formwork

• The OR-1.5 formwork is designed for operation as a site for the equipment of the MNB-50 machine and for protection of personnel and equipment against soil collapse
• The inner dimensions of the formwork are designed for installation of reinforced concrete rings for wells, having diameters up to 1.5 m.

The OR-1.5 formwork provides safety of operation and minimal scope of excavations for work at high depth.

• Reinforced concrete rings are installed inside the formwork.
• Two hydraulic cylinders, with the load-bearing beam resting on a reinforced concrete ring, are used to lift the formwork belts.
• With the formwork belts extension, fill-up soil is used to fill resulting spaces between rings and the formwork.
• This is followed by installation of the next ring.
• Then the procedure is repeated.
