Mempex - Model UNB-40 -Directional Drilling Unit
This is a small-sized directional drilling unit for quick construction of pipelines, with the pulling capacity of 40 tons. UNB-40 is a heavier and more powerful version of UNB-20. It is a pit-launched machine based on the principle of dry compaction. Increased pushing and pulling force allows installing new pipes as large as 315 mm in diameter at the distances of up to 120 m. Pipe-bursting capabilities are also increased to 315 mm.
The trenchless procedure for construction of pipelines having the diameter up to 315 mm, up to 120 m long:
- The dry method for pipe-jacking, controllable in terms of plan and profile, with no soil carried away from the working passage.
- Worn pipeline replacement.
- from the pit in the box.
No bentonite mixtures required.
Soil types: up to and including the 3rd category.
Drilling parameters:
- Pipe-jacking length: 120 m*.
- Diameters of pipes to be laid:
63 mm, 90 mm, 110 mm, 160 mm, 200 mm, 225 mm, 250mm, 315 mm.
- Personnel required for works: 2 persons.
Worn pipeline replacement parameters:
- New pipeline diameter**:
110 mm, 160 mm, 200 mm, 225 mm, 315 mm.
- Minimal old pipeline diameter: 100 mm.
- Replaced pipeline length: 120 m.
- Personnel required for works: 2 persons.
Pipeline types:
- Water and sewerage
- Gas
- Conduits for cables used for various purposes
Replaced pipeline material:
- Cast iron
- Reinforced concrete
- Ceramics
- Asbestos
- Steel
New pipeline material:
- Polyethylene
- Steel
