Messotron - LVDT Sensor DAA
Inductive LVDT sensor. Integrated electronics. robust housing 25mm. High quality linear bearings. Measuring range 25 ... 1000 mm. Supply 24 VDC. Output 4...20mA / 0...20mA. With free or guided Core rod. Versions with articulated eyes available.
Most popular related searches
Supply: 22 ... 26 VDC / 40 mA, stabilized
Output signal: 4 ... 20 mA
max. load: max. 400 Ohm
Static resolution: continuous
elektr. Grenzfrequenz: 100 Hz
Linearity**: ±0,5 % F.S.O. Option: ±0,25 %
Temperature coefficient of zero: ±0,1 % / 10 K
Temperature coefficient of span: ±0,2 % / 10 K
Operating temperature: 0 °C ... +60 °C
Protection (DIN 40050): IP 65 except for connector (IP 67)
