Sunkye - Micro Solder Cup Connectors

PLASTIC SHELL of Micro Solder Cup Connectors

• Ideal for prototyping or where pigtail type connectors cannot be used.
• Plastic connector and solder cup contacts.
• Ideal for prototyping or where pigtail type connectors cannot be used.
• Operating temperature: 150°C or 200°C.
• 9 to 51 contacts.

Contact arrangements of Micro Solder Cup Connectors

• Metal shell: 9, 15, 21,25,31,37,51,66,74, 100 contacts
• Plastic shell: 9, 15, 21,25,31,37, 51 contacts

Introduction of Micro Solder Cup Connectors

• Series * Micro D Connector
• Terminal Mounting * Solder Cup type

• Contacts *Twist pin contacts, high-density interconnection, Becu, gold over nickel plating
• The thickness of Gold plating * ≥1.27micron
• TWIST PIN * Male contact, fitted to plug connector.
• Socket * Female contact, fitted to socket connector (also known as a socket).
• Insulator* 20% GFPPS (20% glass-filled polyphenylene sulfide)
• LCP * Liquid Crystal Polymer.
• Potting * Epoxy compound used as an encapsulant
• Insert * Moulded insulation housing, separating each connection.
• Interfacial Seal * Fitted to socket connector only
• Shell *Connector metal body plated nickel or cadmium.
• Jackscrew *High or low profile, hexagonal socket or slotted head.
• Jackpot* Mates with a jackscrew.
• Standard connector * Manufactured to the standard dimensions and specifications.
• Special connector * A standard connector modified to meet specific requirements.
• Custom made connector * Designed to meet specific customer requirements.
• Solder cup connector * Connector with solder type contacts, usually used for prototyping.
