Milky - Model 100 LPH -Milky Homogeniser

Physical Condition

• Model: GMP
• Code: Good Engineering Practice
• No. of stages: Double Stage
• No of Plunger: 3 Nos
• Plunger Dia: 16mm
• MOC of Plunger: Special alloy with hard chrome plated
• Homogenizer Speed: 265 SPM (Suitable for Continuous duty)

Main Components

• Electric Drive Motor: 2HP Squirrel cage induction Motor at 960 RPM
• Drive Mechanism: Direct Belt drive
• Motor Mounting: Foot mounted
• Seal: Teflon/canvas/equivalent
• MOC: SS-304
• Coolant: Water
• Coolant Temperature Required: Ambient
• MOC: SS -304
• Piston MOC: SS -304
• MOC of Homogenizer valve, Valve Set: Stellite reinforced

Material Of Construction

• Product Contact Parts: SS -304
• Non contacts: MS
• Motor Mounting Skid: MS Frame

Inlet And Outlet Connection

• MOC: SS -304
• Size: 25 mm for Inlet and 25 mm for Outlet
• Type: SMS
• Inlet   Connection: SMS union 25MM
• Outlet Connection: SMS union 25MM

Electrical Controls

• Control: Push button, (Starter not provided).
• Painting: The inner part of the housing white colour two coats. The outer casing painted with expose paint of two coats.
• Tool Kit: Tool kit as add on with machine

Utility Required

• Power supply: 3Ph/415V/50HZ/AC
• Total load: 1.5KW/2HP 960RPM
• Cable Size: 1.5Sq-mm 4 Core-Copper
• Free Space Required: Minimum 1metre all sides
• Pressure Gauge: Flat diaphragm Type (0-400 Bar)
• M O C of all fluid Contact Surface: SS -304
• Homogenizer Covering: SS- 304 Panel
• Oil Window: Provided oil window shows level of oil in crank case
