Mindfull - Model UM-3 -Digital Thickness Tester

Digital thickness tester is an accurate thickness tester with single crystal sensor,which applies multiple echoes to improve the accuracy,the resolution can reach 0.001mm,the limit thickness can reach 0.30mm,UM-3 has two working modes:normal mode and precise mode.The normal mode adopts interface wave-echo method,test range is 1.5mm-20mm;precise mode adopts echo-echo method,range is 0.30-10mm. It is suitable for measuring thin materials,can accurately and reliably measure 0.25mm flat sheet metal material. It can penetrate the coating,such as paint layer.
