Mda compaction / Metallurgie des Appalaches
Mini-Baler
Motor 1 HP 115 V. 1 Ph. 60 Hz. 0.75Kw. ( Option : 220 volts ). Manual control. CSA approved. Control panel protected by fuse. Option: motor 3Hp 600v. 3Ph 60 Hp. 2.25 Kw
Most popular related searches
Technical Description
Electrical :
- Motor 1 HP 115 V. 1 Ph. 60 Hz. 0.75Kw
( Option : 220 volts ) - Manuel control
- CSA approved
- Control panel protected by fuse.
- Option: motor 3Hp 600v. 3Ph 60 Hp. 2.25 Kw
Hydraulic :
- Hydraulic pump 1,2 GPM- .07569L/S
- Operating pressure 14000 PF - 62272 newtons
- Hydraulic pressure 2000 PSI. - 138 bars
- Compacting force 23 PSI. -16171 kg/m2
- Hydraulic cylinders: 1 cylinder de 3` de diameter- 76,2 mm with rods of 1½` de diameter - 38 mm and a stroke of 24`- 609 mm
- Option: pump 2 GPM
