UniVac - Model SC 45-55 E AV4-6-9AR.C -Mobile Electric Suction Unit

The suction unit is composed of a lobe pump with input and output safety filters, an electric motor and an electric control panel. The storage tank with capacities from 4 to 9 m3 It integrates the filter unit with an automatic counter-current cleaning system for the bag filters, a separator cyclone placed at the inlet and a dust level control probe that stops the machine when the maximum material level is reached. The container is unloaded by tilting, by means of a hydraulic cylinder located in the lower part and controlled by a control unit and a hydraulic circuit

The cleaning of the polyester felt filtering sleeves with internal tensioning springs is carried out with a timed automatic counter air wash system through the opening and closing of pneumatically operated valves, thanks to the use of a compressor on the machine.

This kind of vacuum units may be certified according to ATEX Z22 norms.
