Modcon - Model 1060 -Hydrogen Analyzer

Why Choose the MOD-1060 Hydrogen Analyzer?

• Outstanding precision and speed in hydrogen concentration measurement: The MOD-1060 Hydrogen analyzer features an industry-leading response time of < 30 ms and a measurement range from a few ppm to 100 vol.%, specially developed for the new requirements of hydrogen infrastructure in the energy and process industries.
• Unrivalled robustness for demanding environments: Optimized for use in humid environments, the device withstands condensate and water without damage and provides precise measurements up to a pressure of 200 bar – ideal for electrolysers, fuel cells and other hydrogen applications.
• Maximum safety, minimum maintenance: With fast and reliable explosion level monitoring, the MOD-1060 significantly increases occupational safety. The device is a long-term investment with an expected service life of up to 10 years.
• Adaptability meets economy: The extremely compact MOD-1060 saves space and costs. Thanks to it, a wide variety of gas mixtures can be measured without additional sample preparation – a highly efficient solution that outperforms the competition in terms of performance and price.

Ensure your hydrogen monitoring is in safe hands with the MOD-1060 Hydrogen Analyzer.

• Thermal Conductivity-Based Measurement: The MOD-1060 operates using thermal conductivity (TCD) technology, providing reliable hydrogen concentration measurements even in dynamic environments.
• Wide Measurement Range: The MOD-1060 is capable of detecting hydrogen concentrations from low ppm levels up to 100%, making it suitable for diverse applications in industries such as petrochemical, energy, and environmental monitoring.
• Explosion-Proof Design: The analyzer is housed in an Ex d enclosure and certified for operation in hazardous environments. The MOD-1060 meets ATEX and IECEx standards, ensuring safety in environments with potential hydrogen hazards. Safety integrity level certified: SIL2 as per IEC 61508-2:2010 (020195:3266-1-P1)
• Ultra-Fast Response Time: With a response time of less than 30 milliseconds, the MOD-1060 provides near-instantaneous measurements, essential for real-time monitoring and fast adaptation to changing hydrogen concentrations.
• Flexible Integration: The analyzer can be easily integrated into existing systems via 4-20 mA analog output for data transfer.

Contact us to learn more about MOD-1060 Hydrogen Analyzer

• Hydrogen Industry and other Renewable Energy: Measuring hydrogen levels in fuel cells and electrolyzer applications to ensure optimal performance and safety.
• Petrochemical Industry: Monitoring hydrogen concentration in refining processes and ensuring safe operating conditions in explosive environments.
• Chemical Processing: Continuous hydrogen monitoring in chemical reactors to maintain the desired reaction conditions.
• Environmental Safety: Detecting hydrogen leaks in storage facilities and monitoring emissions to meet environmental standards.

• Measurement Range: 0-100% hydrogen concentration
• Response Time (T90): Less than 30 milliseconds
• Outputs: 4-20 mA, RS-485
• Power Supply: 24 VDC ±25%, 5 W
• Hazardous area: ATEX/IECEX Zone 2 , Zone 1
• Safety integrity level: SIL2
• Operation Temperature: -40°C to 90°C / 125°C (option)
• Gas Pressure (Absolute): 0.8 – 200 Bara
• Accuracy: Less than 50 ppm
• Process connection: NPT ½”
