Model 70Z7 T4F -Wheel Loader

ENGINE

• Air cleaner, double element
• Auto idle shut down
• Cold start (Intake Air Heater)
• Cooling fan, automatic reversible, swing-out type
• Rain cap
• EGR system
• Fuel filter (Main)
• Fuel Pre-Filter, w/water separator
• Cummins QSB6.7 diesel engine
• SCR catalyst and DOC
• VGT (Variable Geometry Turbocharger)
• Work mode selector

 POWERTRAIN

• Brakes, service, Enclosed wet disc, Dual system, Inboard mounted
• Brake, parking, Spring applied , Oil pressure released, Dry disc type
• Differential, limited slip type (F/R)
• Down-shift switch
• Drive shafts, low maintenance
• F-R direction selector (2-Column mounted/hydraulic control lever mounted)
• 1st speed hold switch on side console
• Quick power switch
• Transmission, automatic w/load sensing system
• Transmission declutch (3-position L/H/Off)
• Transmission mode selection (3-position AUTO1/MAN/AUTO2)
• Universal joints, sealed

HYDRAULIC SYSTEM

• Boom kick-out, dual (operator adjustable in cab)
• Bucket positioner (horizontal)
• Control lever, single, pilot-assisted
• Control lever lock (electric)
• Control valve, 2-spool, parallel and tandem control
• Pump, variable displacement, load-sensing
• Steering, direct
• System; open-center, high-pressure, load-sensing


ELECTRCAL

• 24-volt electrical system
• Back-up alarm
• Batteries (2), 12V, 1,000 CCA
• Battery disconnect switch
• Camera, rear-view
• Converter, 12V/15 amp
• Horn, dual electric
• Instrument panel, LCD, color

Lights:
    2 Headlights (halogen)
    2 Forward working lights (halogen)
    4 Rear working lights (halogen)
    2 Stop/tail/backup (LED)
Turn signal w/4-way flashers/marker

CAB

• ROPS cab: Enclosed cab with sound suppression, front & rear wipers and washers, two rear view and side mirrors, tinted glass, full view latch-back doors, sliding side windows.
• Accessory outlet, 12V
• Adjustable armrest/console,(fore/aft sliding)
• Air conditioner/heater/pressurizer
• AM/FM/WB radio with AUX input
• Ashtray
• Cab dome lamps (2)
• Cigarette Lighter, 24V
• Coat hook
• Cup holder (2)
• Floormat, sweep-out
• Retractable seat belt (3 inch)
• ROPS/FOPS certified
• Seat, air suspension, fabric
• Steering column, telescoping and tilting w/quick-release pedal
• Steering Wheel
• Storage box (heated/cooled)
• Storage tray
• Sun visor


Others

• Articulation locking bar
• Counterweight
• Drawbar
• Fenders, front, w/mudflap
• Fenders, rear, deck-type, w/mudflap
• KCM Global e-service, telematic monitoring system (GSM-version w/4 years service)
• Ladders, inclined
• Lifting eyes
• Linkage Pins, HN Bushing
• Neutral safety start
• Rear grill, hinged
• Steps, rear
• Vandalism protection
• Z-bar loader linkage

OPTIONAL EQUIPMENT

• Autolube
• Belly guard, transmission
• Bolt-on cutting edge & segments
• Bucket teeth
• Dual lever hydraulic control
• Fenders, rear, full w/ mudflaps
• HID work lights
• High lift boom arm
• Hydraulic system, 3 spool valve
• LED work lights
• Quick coupler and attachments
• Ride control, automatic
• Seat, heated
• Secondary steering
