Model AFP -Axial Flow Plug Fan
Daniels Fans manufactures high temperature industrial axial fans in belt drive and direct drive. Impellers can be reversible with equal volume in both directions. Shafts are air cooled – no water cooling required.
Performance Range
Volume – 9000 to 118000 CFM / 15000 to 200000 m3/h
Static Pressure – Up to 4″ @ 70°F / 100mm @ 20°C
Maximum Temperature – 1750° F / 950°C
Design/Construction
Type – Axial Flow Plug Fan
Diameters – 24 to 72 inches / 610 to 1830mm
Shaft – Air cooled
Construction Materials
Steel – Weldox, Other Grade
304 – Stainless Steel
316 – Stainless Steel
309 – Stainless Steel
310 – Stainless Steel
321 – Stainless Steel
330 – Stainless Steel
Duplex Stainless Steel 2205
Incoloy 800 and 800H
Inconel 617
HR120 Alloy
Typical Applications
Heat treating air circulation
Preheating
Homogenizing
Annealing
