Model AMI Codes-II -Colorimetric Process Analyzer

• For the continuous online determination of disinfectants based on the DPD colorimetric method (EN ISO 7393-2; APHA 4500 Cl-G.
• Also applicable for water containing additives like corrosion inhibitors, cyanuric acid and antiscalants.
• Measurement values: Free chlorine, chlorine dioxide, bromine and iodine, monochloramine or ozone.
• Complete system including measurement and control electronics, photometer, flow indicator, reaction chamber, reagent dosing system and reagent containers.
• Integrated pH measurement with temperature compensation (available as option).
• All usual dosing devices for disinfectants and pH control can be connected either through relays or analog output signals. Two independent controllers can operate simultaneously.

Options:

• pH option containing pH sensor, temperature sensor, cables and electronics board.
• Third signal output selectable as:
  - Current signal output
  - Interface RS485 (Profibus DP or Modbus)
  - Logger download kit (with HyperTerminal)
• Chemical cleaning module.
