Model AW-D101 -Addressable Smoke Detector

SHARE

Asenware AW-D101 smoke detector is an intelligent smoke detector, which can be configured with Asenware AW-FP100 Series Addressable Fire Alarm Control Panel. Each point (devices) can be given specific ID, which allows the panel to continuously monitor specific detector location (point). It reduces the maintenance cost and makes it easier to maintain the system.

Most popular related searches
addressable fire alarm control panel
smoke detection system
addressable fire alarm
fire alarm control
fire alarm control panel
fire alarm
fire control panel
fire alarm panel
fire panel
addressable fire panel
  •  Addressable-analog communication
  • Low standby current for continuous monitoring (≤2.5mA)
  • Two-wire connection
  • Two LEDs (RED), blinks in normal condition and becomes stationary during fire
  • Remote test from Panel


Spacing
Spacing of detector must be followed by standard EN 54 or NFPA 72. NFPA 72 suggests for low airflow application spacing of 9.1 m for ceiling height up to 3.15 m can be applicable. However, please follow the specific codes and local codes for specific applications.
