Model AW-FP100 -Addressable Fire Alarm Control Panel
Asenware AW-FP100 Series Fire Alarm Control Panel are intelligent panel which are carefully designed to make it suitable for most of applications. It can be configured with other panels or control systems. It’s user friendly functionality makes it suitable to program and configure the devices. 7” touchscreen display gives the information for fire alarm, trouble , supervisory and other related information all the time.
Most popular related searches
fire alarm control panel
fire alarm control
addressable fire alarm
fire alarm
addressable fire alarm control panel
fire control panel
fire alarm panel
fire panel
addressable fire panel
level controller
7” Touchscreen LCD Color Display which gives necessary and additional information as described in EN:54-2
- Delay function for zones for Notification Appliance
- Circuits (NACs)
- 2 wire cable for all addressable devices
- Zone test and individual device testing
- Zone Disable and individual device isolation
- Delay, override and abort functionality
- User friendly : easily configurable windows using Panel itself
- 250 intelligent detectors or modules for one loop circuit
- Up to 8 Loop cards can be installed and configured
- Interconnection of ….panels and other equipments
- 2000* events can be stored in the history
- Mini- Printer to print the status of events
- Network with Central Control Panel
- Access Level entry to control and configure panel
- Integral power supply with charger
- Circuits can be configured as Class A or Class B
- Fire Alarm, Fault (Trouble) and Supervisory relays
- Earth Fault detection
- CAN BUS Network System
- Network Available Options : GSM/IP/Cloud/ Mobile APPs
