Model CTD75M -Medium Sized Multiparameter Probe

Sea and Sun Technologies CTD75M offers excellent reliable performance in limnological, oceanographic, and off-shore areas. The probe is offered for two different applicable depths, 500 m and 2000 m. The CTD75M is a high accuracy probe that measures conductivity, temperature, and pressure as a standard configuration. Furthermore it can be easily configured for a wide range of auxiliary sensors. More detailed information on the sensors can be found in the table below. Sea and Sun Technologies CTD75M records selected data at programmable time intervals whereas the data is stored in a non-volatile FLASH memory with a capacity of 128 Mbytes. A standard RS-232 connection is used for programming, data output, and data acquisition. Data is available as RS 232 signal and optional in online mode as digital FSK signal modulated on constant current.

Most popular related searches

multiparameter probe

conductivity monitoring

temperature monitoring

A microprocessor controls the 16 bit analog to digital converters
that have 8 channels. Therefore the probe can be equipped with
8 sensors. Additionally the CTD75M is equipped with an USB Port
for fast data retrieval and configuration in laboratory. All calculations
correspond to the UNESCO formulas. A Standard Data Acquisition
Software package “SSTSDA” compatible for Win” 95/98/
Windows07©” provides probe configuration, probe service, data
acquisition and offers visualization of data via graphs. An underwater
bulkhead connector SUBCONN MCBH8M is used for communication
(configuration and data retrieval) and external power supply.
The power supply of the probe is activated by touching a reed
contact with a magnetic rod. LED displays power supply status and
optical control of memory access.
