Model DCAT 25 -Premium Force Tensiometer
The DCAT 25 is the multifunctional all-round model of the series, which can be equipped with many modules and software functions. Due to the closed sample chamber, measurements can be carried out at defined humidity and temperatures (-15 °C and 300 °C). In addition, it is possible to investigate the viscoelasticity of monolayersas well as the adhesive force of materials thanks to the Langmuir trough and the UpVideo DCAT camera module, respectively.Most popular related searches
force tensiometer
Pt100 temperature sensor
sampling chamber
digital temperature controller
weighing system
temperature sensor
dosing system
temperature monitoring
temperature monitoring system
humidity measurement
- surface and interfacial tension
- liquid density and solid density
- dynamic contact angles
- surface energy of solids
- automatic determination of the critical micelle concentration (CMC)
- sedimentation and penetration
- analysis of adhesive force
- surface pressure
- viscoelasticity of monolayers
- electrodynamic compensation weighing system with a resolution of up to 10 μg and with automatic as well as manual calibration function
- software-controlled, motorised height positioning of sample vessels at variable speed
- automatic coupling lock for the weighing system
- automatic collision protection for sample bodies during measurement
- closed, illuminated sample chamber for measurements at defined humidity and temperature
- built-in magnetic stirrer
- digital thermometer with ports for two Pt100 temperature sensors
- upgradeable with the LDU 25 liquid dosing unit for the automated generation of concentration series to determine critical micelle concentration (CMC)
- upgradeable with various temperature control systems for measurements at temperatures between -15 °C and 300 °C
- upgradeable with the UpVideo DCAT camera to analyse the force of adhesion per area
- upgradeable with Langmuir trough module LTMr for the investigation of monolayers
