Model FCA -Trapezoid Sheet-Metal Foldable Storage Container for Combustible Material with Wooden Bottom

SHARE

Foldable storage containers are made of trapezoid sheet-metal of 0,75 mm thickness, bearing sections of 2 mm thickness and wooden bottom of 35 mm thickness. A double-wing door with a handle and a lock are placed in the front wall and a single/double door in the side wall. The container is equipped with cradle attachments. The containers are delivered dismantled and may be stacked up to 7 layers. It is possible to combine various lengths on a truck. It takes 1 - 2 hours to assemble. The containers may be also delivered assembled. The FCA storage containers do not include a spill pallet. The FCB containers are fitted with a spill pallet made of 2,5mm-thick metal-sheet. The volume of the pallet is either 275 litres in case of a 3-meter-long container or 202 litres in case of a 2-meter-long container

Most popular related searches
Maximal loading
  • 1500 kg for crane handling
  • 3000 kg for fork-lift truck handling
  • surface loading of bottom 500 kg/m3.
Options
  • racks and girders
  • retaining shelves for container 2 and 3 meters
  • connecting kit for lengthwise connection of two containers
  • second door instead of rear wall (double-wing door)
  • window and shutter 850x750 mm in side/rear wall
  • window without shutter 300x577 mm in side/rear wall
  • guides for fork of fork-lift truck
  • floor with hot-dip galvanized surface finish (in length 2 and 3 m with double-wing door)
  • surface finish of external surface coated with powder paint
  • a bar on single/double-wing gate
  • ventilations grilles
