Model G10 -Gamma Beam Irradiator
The Model G10 Gamma Beam Irradiator is well suited for health physics instrument calibration. The horizontal free-in-air radiation beam provides uniform and precision dose rates. The ISO-4037 collimator minimizes scatter. With 2 sources and the attenuator set, the dose rate can range over six orders of magnitude. A simple design and quality manufacturing assure this system will operate reliably for decades**. The system may be controlled by a computer or an electronic controller (PLC+HMI). There are six configurations to choose from based on source quantity and size.
- Single or dual source models
- Available with Cesium-137 and/or Cobalt-60 sources
- With source options and attenuators, exposure rates are available from 1 uSv/hr to 100 Sv/hr
- High precision and repeatability assure accurate calibrations with low uncertainty
- Collimated and uniform beam profile
- Electronic operation or fully-automated computer control
- Computer control provides extensive automation to reduce errors and improve efficiency
- Easy to use with an intuitive operator interface
- Inherent fail-safe design
- Highly reliable
- Calibration available with traceability to NIST
Dose Rate: 1 uSv/hr (0.1 mR/hr) to 100 Sv/hr (10,000 R/hr)
Cesium 137 Sources: 0.4 GBq (10.8 mCi) to 65 TBq (1757 Ci)
Cobalt-60 Sources: 0.4 GBq (10.8 mCi) to 37 GBq (1 Ci)
Collimator: ISO4037 17° or custom design
External exposure rates: <2 uSv/hr (0.2 mR/hr) @ 30cm (11.81”) from the surface
Size: Nominal 40cm (15.75”) x 70cm (27.56”) x 160cm (63”) tall
Weight: 300 to 900 kg (661 to 1,984 lbs) depending on model
Power: 120/220 VAC, 50/60 Hz, 1500 watts
- Model T20 precision linear positioning track, manual or automated, 1 to 4 axes
- 0 - 8000X attenuator Set
- Additional collimators for different beam sizes
- Safety interlock system
- Video cameras for instrument and room viewing
- Jigs/fixtures
- Dosimeter phantoms
- Laser alignment
- Temperature, Pressure, Humidity Monitors
- Calibration equipment & service
