Model GC60 -Gamma Beam Irradiator
The Model GC60 Gamma Beam Irradiator is well suited for instrument calibration. The horizontal free-in-air radiation beam provides uniform and precision dose rates. The ISO-4037 collimator minimizes scatter. With a capacity for 6 sources, it offers the maximum flexibility in configuration and future expansion. Sources can easily be added and changed at a future date. The system may be controlled by a computer or an electronic controller (PLC). Three configurations are available based on source size.
Most popular related searches
temperature and humidity monitoring
humidity monitoring system
laser alignment
humidity monitoring
precision dosing
pressure monitoring system
safety system
pressure monitoring
humidity calibration
temperature monitor equipment
- Up to 6 Sources + 1 Test Capsule
- Available with Cesium-137 and/or Cobalt-60 sources
- With source options and attenuators, exposure rates are available from 1 µSv/hr to 10 Sv/hr
- High precision and repeatability assure accurate calibrations with low uncertainty
- Collimated and uniform beam profile
- Fully-automated computer control provides extensive automation to reduce errors and improve efficiency
- Easy to use with an intuitive operator interface
- Inherent fail-safe design
- Highly reliable
- Calibration available with traceability to NIST
- Cesium-137 Sources: 370 MBq (10 mCi) to 100 TBq (2700 Ci)
- Cs-137 Dose Rates: 1 µSv/hr (0.1 mR/hr) to 6 Sv/hr (600 R/hr)
- Cobalt-60 Sources: 370 MBq (10 mCi) to 370 GBq (10 Ci)
- Co-60 Dose Rates: 1 µSv/hr (0.1 mR/hr) to 10 Sv/hr (1,000 R/hr)
- Collimator: ISO-4037 17° or custom design
- External Rate (Shielded): <50 µSv/hr @ 30 cm (<5 mR/hr @ 12”) from the surface
- Size: 980 mm x 815 mm x 2,320 mm (38.5” x 32” x 91.25”) (Width x Depth x Height)
- Weight: 2,360 to 4,660 kg (5,200 to 10,275 lbs) depending on model
- Power - 120/220 VAC, 50/60 Hz, 1500 watts
- Safety Interlock System
- 0 - 8000X Attenuator Set
- Additional collimators for different beam sizes
- Model T20 precision linear positioning track, manual or automated, 1 to 4 axes
- Video cameras for instrument and room viewing
- Jigs/fixtures
- Dosimeter phantoms
- Laser alignment
- Temperature, Pressure, Humidity Monitors
- Calibration equipment
- Routine Maintenance/Service contract
