Model H2 SS -Hydrogen Raw Sensor

Operating Principle: Amperometric, 3-electrode cell. Gas Detected: Hydrogen H2. Standard Range: 0 –20,000 ppm. Lower Detectable Limit (LDL): 100 ppm. Maximum Range: 40,000 ppm. LEL:  40,000 ppm. Expected Operating Life: 5 years. Temperature Range: -20oC to +80oC. Humidity Range (non-condensing): 15-90% RH. Response Time (T50): <10 seconds. Response Time (T90): <30 seconds. Long Term Sensitivity Drift: <10% per year. Deviation From Linearity at Standard Range:  <20% FS. Zero Current at Normal Conditions: +/-100nA. Sensitivity: 0.4 –10.0 nA/ppm. Sensor Warm-Up Time (typically):  20 seconds. Temperature Dependence: <0.5% per oC. Sensor dimensions: 10mm x 8.8mm x 3mm. Warranty Period: 2 years from date of despatch. Part Number: 2112B010210.
