Model IPTF 7450 DR -Thermoform
With Inan Plastik Thermoforming machines, you can package food, industrial, medical, and consumer products both efficiently and economically.
Most popular related searches
- Capacity : 0 – 45 cycle
- Max. Forming Area : 750 x 500 mm.
- Sheet Raw Material Width : 780 mm.
- Sheet Raw Material Thickness : 2 mm.
- Pitch : 520 mm.
- Crushing Force : 32.500 daN
- Forming depth : 150 mm.
- Compressed Air Requirement : 9 m? , 8 bar
- Electrical Power Requirement : 222.11 kW (at max. load)
- Water Pressure and Temperature : 3,4 bar, 8°c , 50.000 kcal
- Weight : 15 tons
- Usable Raw Materials : PP,PS ,PET,ABS,PE
- Number of resistances : Longitudinal top 152 pieces, bottom 132 pieces
- Min. Collation quantity : 30 pieces
- Max. Collation Quantity : 100 pieces
- Elevator Servo Motor Power : 0,93 kw
- Rotation angle : 180 °
- Product discharge : Konveyörlü
- Collator motion Gear Motor : ?
- Elevator Stacking System : ?
- Adjustable Conveyor speed : ?
