Model KNZD-70 -Passenger Assistance Intercom
Passenger Assistance Intercom is a set of modern residential service measures, providing two-way video communication between visitors and staff member, to achieve double recognition of image and voice, thereby increasing safety reliability, saving a lot of time and improving work efficiency.
Most popular related searches
The passenger assistance intercom will be designed to work on apartment, hospital, school, metro…Housed in robust metal body, vandal resistant and tamper-resistant. Assistance intercom ensure voice loud and clear. Good looking, durable, easy to install, comfortable buttons, and low power consumption.
Unit main features
- VOIP Telephone BI-Directional Video telephone Scratch resistant, HD Screen
- SIP supports 5 SIP servers SIP 2.0 Support TR069
- 7" digital TFT-LCD of 1024 x 600 pixels with Visual angle adjustable display screen
- sensor camera with 5Mega pixels 2xLAN, PoE, USB
- TWO group of speed dial for emergency call. Protection: About IP65
- Speaker: 8 ohm 1.5W, loudness 85dB(A) to 65dB(A) MIC’s working distance 80cm
- Ring: >95dB. Coverage 1.5m radius
- The call button is flash when ring, lighting during a call, off when standby.
- With induction loop coverage 1M radius. Metal body
- Braille words for disable.
- HD voice with high quality headset/HD voice in speakerphone mode
- VoIP SIP2.0 telephone DTMF dialing
- MTBF:100000hours MTTR: 2 hours
- Hotline (maximum length of each number is 16 digits)
- Communication: Full duplex 2-way hands-free communication
- Call Control Signaling:VOIP SIP Info(DTMF), RFC 2833(DTMF)
- Power:Power over Ethernet, IEEE802.3af, Class 0 Local power, 12VDC,Idle 2W, Max 10W
- Auxiliary Contacts:1 Aux Output, dry contact
- Contact Ratings. Load: Resistive load
- Rated load:0.3 A at 125 VAC; 1 A at 30 VDC
- Rated carry current:1A
- Max.switching voltage:125 VAC,60VDC
- Max.switching current:1A
- Audio Codes:G.711, G.722, G.729
- Network:10/100 BaseTX Ethernet, RJ45 connectors, Cat5e or better
- IP Protocols:IPv4, TCP, UDP, TFTP, RTP, RTCP, DHCP, SIP
- LAN Protocols:Power over Ethernet(PoE,802.3af), WLAN(IEEE 802.3af), Network Access Control(IEEE 802.1x),STP(IEEE 802.1d), RSTP(IEEE 802.1d-2004)
- Programming:Non-volatile flash memory programming and configuration through Web GUI
- Management and Operation:DHCP and static IP, remote automatic software upgrade, centralized monitoring, status LED
- Echo cancellation code:G.167/G.168
