Model LT 2 -Passage Rotary Union

SHARE

Designed for air, vacuum and fluid use, the 2 passage LT Series rotary unions are ideal for a number of automation and robotic applications. All LT Series rotating union designs feature aluminum construction for low weight and excellent durability.

  • Max. Pressure¹600 PSI (40 BAR)
  • Max. Vacuum¹30 HG
  • Max. Rotational Speed¹500 RPM
    • Please note operational life is dependent upon both rotational speed and duty cycle. Contact DSTI if your application requires operating close to the maximum rotational speed with a continuous duty cycle.
  • Temperature Range¹0° F to 220° F (-18° C to 105° C)²
