Model MS-20 -Wood Crusher

FromJSC Radviliskis Machine Factory

SHARE

Wood crusher MS-20 is used for professional crushing and chipping of various wood waste. Pulverized wood waste (from wood workshops, gardens, parks) can be used in boiler rooms or for individual use. It can also be used for material preparation in wood pellets production.

Most popular related searches

wood waste processing

wood waste crushing

pelleting press

waste transport

wood production

Body
Conveyor belt
Denial drum
Lower steady drum
Upper ranging drum with different gears.
Fraction sieve
Electric motor
Control panel

Wood waste is supplied to the crusher by conveyor belt.
With the help of lower and upper drums, waste is supplied up to denial drum.
Sieve, covering the denial drum, sorts the fraction to the output.

Model: MS-20

Capacity, erdm/h: Up to 15
Denial drum diameter, mm: 420
Input working width, mm: 495
Max diameter of raw material, mm: 150
Blades, units: 2
Drum rotation frequency, RPM: 1050
Waste transportation speed, m/s: 0,1
Main el. engine power, kW: 37
Feed el. engine power, kW: 1,5
Dimentions, m: 1,96x1,1x1,28
Belt transporter length, m: 3
Weight of chipper, kg: 2570
Weight of transporter, kg: 300
Weight of el.box: 125

Used in workshops for various wood waste crushing.
Can be used for material preparation in wood pellets production.
Shortest material size - 50cm.
