Model MU Series -Internal Electric Vibrators
The series MU is designed and conceived for concrete vibrating in Building and in Public Works, warranting a long life and reliable service, offering the best performances with a minimum maintenance service. The motor built in series MU are supplied, in the standard version, to be connected at a three phase safety voltage 42 V 200 Hz obtaining a 12000 r.min-1 turning speed.
Most popular related searches
- Encapsulated stator (maximum electrical and mechanical protection).
- Stator with thermical protection.
- Lubricated by oil.
- Steel or Vulkollan nose.
- Three special long life bearings.
- Housing made of high abrasion resistant steel.
- Internally and externally reinforced hose.
- Extensible rolled wires inside.
- Built-in switch.
- Plug following EC standards.
The MU-26 type is a special designed vibrator to be used in laboratory test tubes. The vibrator is made starting from a MU-36 stator, fitted in a 41 mm diameter sleeve, where another 26 mm diameter and 280 mm long sleeve is adapted.
- Other voltages and frequencies.
- Sleeve with Vulkollan nose.
- Hoses and cables with other lengths.
- Special sleeves for paving.
- Vibrators with pistol handle for prefab construction.
- Specially treated sleeves by Tungstene Carbure for extremely abrasive jobs.
