Model OCA 200 -Expert Contact Angle Meter

SHARE
The expert model OCA 200 is the contact angle measuring instrument for microscopic and macroscopic structures. Thanks to the 10x zoom lens and the autofocus system, it is suitable for any sample size from the macroscopic silicon wafer to the microscopic metal struts of a coronary stent. Together with the FDDS FlexDrop dosing system, the OCA 200 allows the analysis of droplets with a minimum volume of 25 picolitres.
Most popular related searches
dosing system
zoom lens
environmental chamber
automatic monitoring
microscopy
liquid sampling
environmental monitoring
surface analysis
liquid analysis
temperature monitoring
  • static contact angle (sessile drop method, captive bubble method, sessile drop in top view)
  • dynamic contact angle (roll-off contact angle and needle-in method)
  • analysis of interfacial and surface tension with dispersive and polar parts (pendant drop method)
  • analysis of surface energy with dispersive and polar parts (sessile drop method; automatic measuring procedure with several test liquids and sample mapping)
  • analysis of the viscoelastic modulus (oscillating drop method)
  • analysis of the work of adhesion
  • sample stage adjustable in all three spatial directions with precision electronic axes
  • video measuring system with high-performance camera with up to 3250 frames/s and USB 3 interface
  • ground-breaking 10x zoom lens
  • software-controlled autofocus and observation angle adjustment
  • LED illumination with manually and software adjustable intensity including automatic temperature drift compensation
  • TP 50 control panel with touch screen and precision control wheel included



  • compatible with the SD-DM single direct dosing system with one electronic syringe module
  • compatible with the DD-DM double direct dosing system with up to two electronic syringe modules
  • compatible with electronic multiple direct dosing systems DDE with up to four electronic syringe modules
  • compatible with the nanolitre dosing system, which can dose drops with a minimum volume of 10 nanolitres
  • compatible with the PDDS picolitre dosing system, which allows minimum drop volumes of about 30 picolitres
  • compatible with FDDS Flexdrop dosing system, which can dose two drops simultaneously with a minimum volume of 25 picolitre



  • upgradeable with different environmental chambers for measuring at temperatures ranging from -30 °C to 700 °C
  • upgradeable with the manual tilting table TBA 360 and the electronic tilting unit TBU 100
  • upgradeable with the TVS TopView Video System, which allows the measurement of contact angles in indentations
