Model PNL64 -Sampling And Analysis Devices

Intake sampling device, model PDS

• For taking gas and liquid samples
• Volume: 600cm³
• Working pressure: maximum 1,000bar
• Filling of the samples into transport cylinders at reservoir pressure
• Gas and liquid together
• Transport cylinders certified for plane transport

Spherical liner, single, and double ball valve

• For extracting liquids

Liner, without valve

• For extracting or skimming of liquids

Instruments

• Liquid level measuring instruments for measurement on the wire in the unfilled space for 2-3/8`` to 4-1/2`` tubing strings
• Sonolog unit for measuring the fluid level in the annular space and in the unfilled space
• Piezoelectric and quartz pressure-temperature memory gauges; pressure range up to 1,000bar; temperature range up to 177°C
• Mutli-logging tool for profile measurements of pressure, temperature and flow, with CCL sensors; pressure range up to 700bar; temperature range up to 177°C
• Data logger with surface pressure sensors from 60 to 400bar
• Orifice flanges 2-9/16`` API 5,000psi with sensor pockets for temperature sensors
• Measurement with up to 6 channels with sensors for use in hazardous environments
