Model REX Series -External Electric Vibrators

• Disegned for continuous operation at maximum centrifugal force.
• Rugged well dimensioned body.
• Vaccuum impregnated and tropicalized stator.
• Shortcircuited cast aluminium armature.
• Special heavy-duty bearings.
• Large diameter shaft to avoid deflection.
• IP 66 protection.

• The REX vibrators are made to work continuously, at their at maximum centrifugal force, for the whole range.
• The vibrator bodies are rugged well dimensioned.
• The stator, with a B/F isolation, is shortcircuited cast aluminium armature.
• Vaccuum impregnated and tropicalized stator.
• Special heavy-duty bearings are mounted.
• Large diameter shaft in order to avoid deflection.
• IP 66 protection for the whole range.

The vibrators belonging to the REX serie are made, in the standard version, to be connected at a three-phase 230/400 V 50 Hz. Nevertheless, under request, other voltages or frequencies can be supplied.
