Model Series-2 -Economical Digital Force Gauge

Series 2 digital force gauges are designed for basic tension and compression force testing applications up to 500 lbF (2500 N). Peak tension and compression readings are reliably captured via the gauges` ±0.5% accuracy and 500 Hz sampling rate. A backlit graphic LCD displays the current, peak tension, or peak compression reading.  The gauges are overload protected to 150% of capacity. An ergonomic, reversible aluminum housing allows for hand held use or fixture mounting, rugged enough for applications in both production and laboratory environments.
