Dab Pumps S.p.A.

Model SINTESI Series -Single Phase Motor/Pump Protection and Control Panel

SHARE

Single phase motor/pump protection and control for direct start up.Casing made of shock-proof and selfextinguishing thermoplastic material with two antipull plugs. Main switch with operating light. Single phase power supply 230 V +/- 5%.Powers from 0.5 HP to 3 HP. Protection degree IP43. Starting Capacitor. Thermal protection with external manual reset. Auxiliary contacts for control by probes, pressure switch and float switch.
