Model SynchroGuard -Grid Monitoring And Automation System

SHARE
SynchroGuard is a pioneering grid monitoring and automation system designed specifically for grid operators, utilizing cutting-edge high-speed and time-synchronized measurements like synchrophasors sourced from Phasor Measurement Units (PMUs). Leveraging patented software algorithms, unique data is extracted from proprietary SynchroSense units and third-party devices. Seamlessly integrated with existing DMS/SCADA systems, it allows operators to visualize grid states and alarms in real-time. The core of SynchroGuard is its scalable and modular software, configurable as either an on-premise or cloud solution. This software reveals hidden information from measurement data, offering operators a real-time grid view, automated control of Distributed Energy Resources (DERs), and fault localization. Its modularity ensures it meets specific client needs, while a decentralized approach significantly enhances grid asset visibility without burdening the DMS/SCADA systems. The accompanying SynchroSense device is an efficient monitoring tool offering rapid, non-invasive installation, embedding multiple high-speed, time-synchronized voltage and current measurements within a single unit.
Most popular related searches
SCADA system
automatic monitoring system
automatic monitoring
SCADA

SynchroGuard is the first grid monitoring and automation system that leverages high-speed and time-synchronized measurements, such as synchrophasors provided by Phasor Measurement Units (PMUs).
Our patented software algorithms extract unique information from data generated by proprietary SynchroSense units and third-party devices.
SynchroGuard seamlessly integrates with DMS/SCADA systems of the utility, where the operators can visualize grid state and alarms in real-time.

The scalable and modular software is the core component of SynchroGuard and can be provided as an on-premise or cloud solution.
Such a software extracts the hidden information out of the measurement data and provides to the grid operator a real-time view of the grid state, enables automated control of DERs and locates faults in the grid.
SynchroGuard software modularity allows to easily adapt to the specific needs of each client. Also, thanks to SynchroGuard decentralized approach, the operator’s visibility on grid assets is considerably increased without overloading the existing DMS/SCADA system with unnecessary calculations.
