Model T100 R Series -Refrigerated Circulating Baths
The Grant Optima™ T100 R series of refrigerated circulating baths with digital control provides excellent value for money for straightforward applications requiring accurate heating and cooling in the temperature range of 0 to 100°C.
The Grant T100 heating circulator incorporates Intelligent Control Optimisation™ (ICO) for adaptive intelligent PID temperature control and can be combined with four of Grant`s refrigeration units.
- Simple-to-use rotor dial with two fucntion keys provide access to the interactive interface for fast, accurate set-up
- Clear 4-digit display for instant reassurance - easy to read from a distance
- Visual alarm - alerts you when your attention is required
- Operating setpoint plus 3 adjustable preset temperatures for convenience
- User calibration facility for optimum accuracy at the required operating temperature
- Choice of four refrigerated (R) tanks with different facilities, working volumes and cooling capacities
- Cooling/heating range: 0 to 100°C
- Stability ± 0.1°C
Note: The refrigeration unit can be switched off indepedendently of the thermostat to allow heating only applications. All the refrigeration base units can be used up to a maximum temperature of 100°C.
* Optima™ heating circulators and accessory pumps can be powered from the back of the R1, R2 and R3 220-240 V refrigeration units. Allow up to 2 kW of extra power from the electrical supply
** The optional VTP pumps will transfer additional heat to the baths and reduce the net cooling power of the refrigeration unit. The above figures must be taken into consideration when choosing the refrigeration unit
Note: when ordering a VTP pump, please specify which refrigeration base unit it is to be used with
