Model TE02/15T -Compacting Press
The compacting press TE02 / 15T has been designed to solve problems deriving from the storage and transport of large quantities of waste. This machine, in fact, has the function of compacting and reducing urban and similar solid waste into bales of adjustable weight, reducing their volume and facilitating their handling.
The TE02 / 15T press must be used exclusively for the compaction of urban solid waste or similar.
The set-up includes: a compaction tunnel inside which a shovel or presser slides which compresses the material against a front door, a horizontal door or guillotine isolates the tunnel from the hopper, the entire structure is supported by four legs (see 3D representation of the exhibition).
The loading normally takes place by means of special conveyor belts which, unloading by falling into a hopper, fill the loading mouth of the Press, at the time of compaction, a horizontal door, moved by an oleodynamic cylinder called guillotine, isolates the compaction tunnel from the hopper.
The compaction of the waste takes place by means of a mobile blade connected to an oleodynamic compaction cylinder. In the front there is the compaction door, where the shovel exerts maximum pressure to form a compacted waste “bale”. This door is raised hydraulically, leaving the entire internal section of the press completely free, and therefore facilitates the transfer of the "bale" onto the means used for receiving.
The machine is marked "CE" in accordance with the standards of the European Community described in the directives:
- 2006/42 / EC (Machinery Directive)
2004/108 / EC (Electromagnetic comp. Directive)
