Model TPH-2T -Multistage Centrifugal Pump
The WALRUS TPH Series is horizontal multistage centrifugal pump, suitable for clean water/liquid without abrasive matters. The applications are versatile, such as pressure boosting, transfer, circulation, and machinery.Industrial circulation systemWashing/cleaning systemPressure boosting systemWater/liquid transferAgricultural irrigation
Most popular related searches
multistage centrifugal pump
centrifugal pumping
centrifugal pump
multistage pump
horizontal multistage pump
horizontal centrifugal pumping
horizontal centrifugal pump
multistage horizontal centrifugal pump
centrifuge
axial pump
Clean or other liquids without abrasive matters
Horizontal multi-stage centrifugal pump, co-axial pump/motor design, impellers mounted on extended motor shaft. All parts in contact with the pumped liquid are made of stainless steel.
- Nominal speed: 3500 / 2900 rpm
- Frequency range: 60 / 50 Hz
- Standard voltages: 220V/380V
- Protection class: IP54
- Insulation class: F.
- Ambient temperature: Up to 40°C / 104°F
- Liquid temperature range: Up to 90°C / 194°F
- Flow: Up to 75 (L/min) / 20 (GPM)
- Head: Up to 80 (meters) / 262 (Ft) / 114 (Psi)
- Operating pressure: Max. 10 kg/cm²
- Inlet pressure: Max. 6 kg/cm²
