Model UHF RFID -Mini Laundry Tag
The waterproof nylon and polyester UHF (860~960MHz) Passive RFID tags are designed for RFID laundry and linen management. The small, rugged RFID laundry tag is made of special material to basically meet all requirements in terms of heat, pressure and chemical resistance in the applications of contactless tracking of garments in the textile rental and dry cleaning.
Most popular related searches
- Type: Contactless R/O or R/W
- Operating Frequency: UHF (860~960MHz)
- IC Available at 860MHz~960MHz: UHF EPC Gen2 (EPC CLASS 1 GEN 2)
- Size: Dia.9mm, thickness:2mm/3mm
- Reading Distance: 1cm ~5cm (Reader Dependant)
- Material: Nylon / Polyester / PPS / EPOXY
- Operating Temperature: -25ºC to 120ºC | +150ºC total 50 Hrs | +200ºC total 20 Sec
- Storage Temperature: -25ºC to 90ºC
- Typical programming cycles at +25ºC: 100, 000
- Typical Data retention time at +55ºC: > 10 years
- Waterproof IP 68 (condition: water pressure 45bar, 10h)
- Data retention time at +55ºC: > 10 years
- 100, 000 times reading & writing
- Exceptional temperature and harsh environmental performance
DAILY RFID is able to design and develop RFID tags and RFID readers in different sizes and different shapes for your different requirement.
