Molecular Distillation Equipment
Molecular distillation equipment is a distillation method operated under high vacuum. At this time, the average free path of the vapor molecules is greater than the distance between the evaporation surface and the condensation surface, so that the difference in evaporation rate of each component in the liquid can be used. The mixture was separated.
The molecular distillation system at a certain temperature, the lower the pressure, the greater the average free path of the gas molecules. When the pressure of the evaporation space is very low (10-2 to 10-4 mmHg), and the condensation surface is close to the evaporation surface, and the vertical distance between them is smaller than the average free path of the gas molecules, the vapor molecules vaporized from the evaporation surface may not be related to Other molecules collide and directly reach the condensation surface to condense.
Vacuum equipment and condensation equipment for molecular distillation:
- Rotary Vane Vacuum Pump
- Desktop circulating water vacuum pump
- Low temperature coolant circulation pump
- Water/oil bath
After sale
- 1 year warranty service and all life maintenance.
- Technical Egineer are avalible for oversea trainning.
- Free change for some parts
- Remote control technical consult
- Free installation DVD
- Maintenance plan
- Very high evaporation efficiency, which reduces retention time with minimal time delay.
- The molecular distillation system is composed of high borosilicate glass, stainless steel and PTFE, so it has excellent corrosion resistance.
- The main body of the molecular distillation system is made of high borosilicate glass, which can well observe the operation of the entire process.
- The high-precision still body makes the liquid form a complete integrated film on the heated surface. The inner wall of the barrel is smooth and clean, the inner wall is smooth and bright, and it is not easy to stick and scale.
- Inverter geared motor, safe and reliable operation; with self-cooling fan, it can work continuously for a long time.
- The entire molecular distillation system has good sealing performance, and the minimum vacuum pressure can reach 0.1Pa.
- The maximum temperature of the system can reach 230 ° C / 300 ° C.
- The maximum theoretical vacuum can reach 5Pa or 0.1Pa.
- Squeegee film forming system and self-cleaning roller film forming system available.
