Baoji - Molybdenum Wire
At Giant Metal, molybdenum wire is processed by the semi-finished products of molybdenum bar. We use the method of hot stretch, repeatedly stretch the molybdenum bar for many times, until make it into wire. In the process of production of molybdenum bar, the exquisite processing technology helps improve the quality of molybdenum bars surface. The defects such as the surface burr and the concave surface are reduced. So the surface quality and the consistency of wire diameter of our production were superior to rotary swaging production of similar products.
- Material: Pure molybdenum, Molybdenum alloy
- Diameter: 0.02~2000mm
- Purity: ≥99.95%, Yttrium molybdenum, Lanthanum molybdenum etc
- Standard: ASTM B387
- Status: Stretching, Polishing
- Shape: Straight, Coil
- Density: 9.8~10.2g/cm3
- Technology: Powder metallurgy
Testing
- Chemical composition test
- Mechanical properties testing
- Appearance size detection
- Metallography detection
Packaging
Coil wire: After the wind and parcel with pearl cotton (expandable polyethylene), then packed in wooden cases.
Straight wire: Pack the molybdenum wire in plastic bags and put in plastic straight barrel, then packed in wooden cases.
- High tensile strength
- High surface finish, good stability, high cutting precision
- Elongation is small
- Rolls with large curvature, the wire diameter is consistent, not easy broken, long service life
- Increase the high frequency power, improve the rough machining efficiency
- Accurate measurement, vacuum packaging, prevent oxidation and mildew, can be long-term preservation
- Molybdenum wire was made by the advanced stretching technology of heat and cold combination, processed the high quality and high temperature molybdenum raw materials into filaments. It is used as wire electrode of wire electrical discharge machining, for cutting machining parts.
- Used for wire core, support, lead wire, heating element.
- Used for high temperature coating, in order to improve the automobile and other mechanical wear resistance of easy worn parts.
