AMCI ControlLogix - Model 3202 & 3204 -Motion Controller Module

Until now, anybody looking for a stepper controller solution to A-B`s ContolLogix platform was out of luck...none existed! AMCI has filled the void by offering the 3200 series stepper control module.

The 3200 two or four-axis stepper motor controller module can control velocity and position of two or four stepper motors simultaneously (note: 3202 also accepts encoder feedback for position monitoring). A wide range of available stepper motor controller commands and benchmark dependability come standard on these high performance controllers.

AMCI`s custom add on profiles make it easy to "add" the 3200 series stepper motor controller module to your Allen-Bradley ControlLogix PLC. No more Generic Module types and you can create custom data tags, simplifying data reference.

AMCI`s 3200 series PLC modules can also control a servo system that has been configured to use step and direction inputs. The same design that positions the 3200 series plc modules as a winning choice for stepper applications, also meets the demands of a servo controller for the ControlLogix PLC.

When your application calls for stepper motor control or servo control solutions, call on AMCI.
