A-Yite - Model GE-131 -Multi-Parameter Water Monitor

FromZHOU ENSI LTD

SHARE

This Multi-Parameter could monitor the PH/ORP Conductive and Temperature at the same time, it was connect with 2 electrode, one is work for PH or ORP(Oxidative redox potential), the other is work for Conductive and Temperature. It could work for Power Station, Petrochemical, Metallurgy, Mining industry, Paper industry, Fermentation Engineering, Medicine, Food & Beverage , Environmentally friendly water treatment, Aquaculture,Modern farming. CE Certification

Most popular related searches

multiparameter water monitoring

multiparameter monitoring

glass electrode

pH/ORP/conductivity

multiparameter water

conductivity electrode

Flexibility, reliability and low maintenance
Temperature compensation
4 alarm relay
2 groups output
RS485//RS232 Communication Interface Optional
Menu operation mode
128*64 Large LCD display

Measuring Range:

pH: 0 ~14.00pH
ORP: -1999mV ~ +1999mV
Conductivity: 0 ~ 100mS/cm
Temperature: -5C ~ 110.0C

The Basic Error:

PH: ±0.01PH;
ORP: ±2mV
Conductivity: ±0.5%FS
Temperature: ±0.3C

Current Output: 0~10mA or 4~20mA
4 Alarm Relay: 3A 240VAC (Max)
Power Consumption: 220V~240VAC Optional: RS485//RS232 Communication Interface

PH/ORP Electrode:

PHD-01: 1-14PH 0~80C glass electrode for sewage, industy water, river water
PHD-02: 1-14PH 0~80C glass electrode for pure water, Boiler water
PHD-03: 1-14PH 0~80C Antimony electrode for Hydrofluoric water
PHD-04: 1-14PH 0~130C PTFE glass electrode for High Temperature water
PHD-05: 1-14PH 0~130C Easyferm Plus 120 electrode for Fermentation & Medicine

Conductivity Electrode:

CED-01: 0 ~ 20μS/cm K=0.01 0~60C
CED-02: 0 ~ 200μS/cm K=0.1 0~60C
CED-03: 0 ~ 20μS/cm K=0.01 0~150C
CED-04: 0 ~ 200μS/cm K=0.1 0~150C
CED-05: 0 ~ 1000μS/cm K=1.0 0~60C
CED-06: 0 ~ 20mS/cm K=10.0 0~60C
CED-07: 0 ~ 100mS/cm K=30 0~150C
