MultiFlow - Model MA -Analogical Dosing Pump With Model Selection
Analogical dosing pump with model selection and manual flow rate adjustment. Analogical dosing pump with selection of flow-rate/backpressure and manual flow rate adjustment The DLX MultiFlow MA is an electromagnetic pump with constant flow rate, manually adjustable via a potentiometer. Max flow rate/working pressure can be selected by the user.
Most popular related searches
dosing pump
solenoid driven dosing pump
pump selection
electromagnetic pump
ceramic ball
level probe
ball valve
solenoid dosing pump
flow regulation
ceramic valve
- Manual adjustment of flow rate
- Regulation range: 0-100%
- Level probe input
- Acid resistant plastic box
- IP65 protetction degree
- Max Flow rate: 50 l/h; Max beckpressure: 16 bar
- Wall or horizontal basement mounting
- Standard pump head: in PVDF, diaphragm in PTFE, seats in FPM, ceramic ball valves*
- Standard power supply: 220-240V**
- Models selectable from the user
- CE certification
*further configurations available on request
**other power supplies available on request
