TOMY - Model SX-700 / 500 / 300 -Multiple Shared Use Autoclave

Ergonomic Height Design
The SX series Autoclaves are designed to be the perfect height to easily load and unload articles into the chamber.

Easy operation using the “Top-open lid”
A top-open lid, which can be operated easily with a single hand and a single foot, is provided. To open the lid, the lid lock is released by stepping on the foot pedal locates at the bottom while pressing the lid down. The lid can be opened with minimal effort owing to mechanical assistance. In addition, the lid can be closed easily just by pressing it down.

Space-saving
The SX series Autoclaves have a small footprint and allow for flexibility in installation locations.
In a comparison of 50L-class models, the SX-500 has a smaller installation space*1 than our previous model.
You can use your laboratory more efficiently and maximize floor space.

Checking the Loading Capacity
Autoclaves are used by various operators in a variety of places, including individual laboratories as well as shared washing rooms, central equipment rooms and so on. And sterilization applications also vary widely for preparation of glassware, preparation of media and distilled water, and decontamination of waste material like petri dishes, etc. Knowing how many articles you want to sterilize can be accommodated will make it easier to plan for sterilization. In the SX-700 as an example, a basket ACA-700B can be loaded with 500ml x 11 bottles or 500ml x 7 flasks, etc.

Intuitive Display
The LED display shows working status for easy monitoring. The process being performed is indicated by an LED indication lamp blinking in red.

Attentive Liquid Sterilization Course
When autoclaving liquid samples, opening the lid while the liquid temperature is high may cause a sudden boiling. It is necessary to allow the pressure and temperature to drop naturally without forced exhaust after sterilization. The SX series Autoclaves have a LIQUID course that automatically sterilizes like this process with a single operation. It reduces spillage of media or solvent inside the chamber and supports smooth shared use in your facilities.

Printer supporting to keep Sterilization Log
Do you have any experience that you were worried if the sterilization was performed as set when you use a shared autoclave in a remote wash room or an autoclave room?
The Optional Printer can print out the operating parameters, chamber temperature, chamber pressure, temperature of articles to be sterilized * and sterilization cycle process.
