nanoLIGHT - Model XUV -Spectrometer & Beam Profiler
XUV beam characterization made easy: the nanoLIGHT combines the functionalities of an XUV spectrometer and an XUV beam profiler in one unit. Quick integration: the entire device is mounted on a standard CF200 vacuum flange. Switching between operating modes or removal from the XUV beam path is completed within seconds.
-
In-situ XUV spectrometer and beam profiler
-
Cost-effective
-
Compact footprint (16x17cm²)
-
Quick mode switching
-
Wavelength coverage 10 - 80nm, recorded simultaneously
-
Insert for thin metal spectral filters
-
Background light reduction jig
A large area MCP combined with a phosphorous screen detects the spectrum. This has the following benefits:
-
broad spectral coverage
-
high efficiency
-
large dynamic range
-
adjustable sensitivity, up to single photon counting
-
low background noise
-
high harmonic generation (HHG) radiation
-
high intensity laser-matter interaction
-
undulator and free-electron-laser (FEL) radiation
-
magnetically confined plasmas
-
fusion research
-
characterization of line-emission sources
